TYK4010型 车床
型号 Model TYK4010 货号 Item No. P4640300 电机功率 Motor power 2.2kw 水泵电机功率 Motor coolant pump 100w 主轴电机功率 Spindle Motor 2.2kw 主轴锥度 Spindle taper MK4 主轴类型 Spindle seat D5 主轴通孔直径 Spindle drilling, rod passage Ø53mm 主轴中心高 Centre height 200mm 主轴中心距 Centre width 1000mm 床身上*大回转直径 Turning Ø over lathe bed Ø400mm 拖板上*大回转直径 Turning Ø over cross slide Ø250mm 主轴转速 Spindle speed 2000/1255/755/460/300/190/155/70 rpm 档位数 steps of spindle 8 小拖板行程 Travel top slide 98mm 中拖板行程 Travel cross slide 185mm 纵向进给范围 Longitudinal feed in the range of 0.014-0.38mm 横向进给范围 Transverse feed in the range of 0.052-1.392mm 公制螺纹范围 Pitch - Metric in the range of 0.4-7mm 英制螺纹范围 Pitch - Inch in the range of 56-4 刀架安装座*大高度 Tool holder seat height (max.) 30m...
分类：
描述
| 型号 | Model | TYK4010 |
| 货号 | Item No. | P4640300 |
| 电机功率 | Motor power | 2.2kw |
| 水泵电机功率 | Motor coolant pump | 100w |
| 主轴电机功率 | Spindle Motor | 2.2kw |
| 主轴锥度 | Spindle taper | MK4 |
| 主轴类型 | Spindle seat | D5 |
| 主轴通孔直径 | Spindle drilling, rod passage | Ø53mm |
| 主轴中心高 | Centre height | 200mm |
| 主轴中心距 | Centre width | 1000mm |
| 床身上*大回转直径 | Turning Ø over lathe bed | Ø400mm |
| 拖板上*大回转直径 | Turning Ø over cross slide | Ø250mm |
| 主轴转速 | Spindle speed | 2000/1255/755/460/300/190/155/70 rpm |
| 档位数 | steps of spindle | 8 |
| 小拖板行程 | Travel top slide | 98mm |
| 中拖板行程 | Travel cross slide | 185mm |
| 纵向进给范围 | Longitudinal feed in the range of | 0.014-0.38mm |
| 横向进给范围 | Transverse feed in the range of | 0.052-1.392mm |
| 公制螺纹范围 | Pitch - Metric in the range of | 0.4-7mm |
| 英制螺纹范围 | Pitch - Inch in the range of | 56-4 |
| 刀架安装座*大高度 | Tool holder seat height (max.) | 30mm |
| 尾架套筒直径 | Tailstock seat | Ø50mm |
| 尾架套筒行程 | Tailstock - sleeve travel | 0-110mm |
| 外形尺寸 | Length x width x height | 1950×820×1530mm |
| 净重 | Net weight | 500kg |
| 毛重 | Gross weight | 598kg |
